SISS08DN-T1-GE3
lmages are for reference only.SISS08DN-T1-GE3
MOSFET N-CH 25V 53.9/195.5A PPAK
DatasheetPowerPAK® 1212-8S
60,720 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 25 V 53.9A (Ta), 195.5A (Tc) 5W (Ta), 65.7W (Tc) Surface Mount PowerPAK® 1212-8S
SISS08DN-T1-GE3
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | TrenchFET® Gen IV |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 25 V |
| Current - Continuous Drain (Id) @ 25°C | 53.9A (Ta), 195.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 1.23mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA |
| Vgs (Max) | +20V, -16V |
| Input Capacitance (Ciss) (Max) @ Vds | 3670 pF @ 12.5 V |
| FET Feature | - |
| Power Dissipation (Max) | 5W (Ta), 65.7W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerPAK® 1212-8S |
| Package / Case | PowerPAK® 1212-8S |
| Base Product Number | SISS08 |
| Gate Charge (Qg) (Max) @ Vgs | 82 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SISS02DN-T1-GE3 | SISS04DN-T1-GE3 | SISS05DN-T1-GE3 | SISS06DN-T1-GE3 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 25V 51A/80A PPAK | MOSFET N-CH 30V 50.5A/80A PPAK | MOSFET P-CH 30V 29.4A/108A PPAK | MOSFET N-CH 30V 47.6/172.6A PPAK |
| Series | TrenchFET® Gen IV | TrenchFET® Gen IV | TrenchFET® Gen IV | TrenchFET® Gen IV |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
