Product CatalogPart Number
SM5S12AHE3-TP
Manufacturer
Micro Commercial CoDescription
TVS,DO-218AB
Datasheet
DatasheetPackage
DO-218AB
In Stock
39,550 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SM5S12AHE3-TP
SM5S12AHE3-TP
lmages are for reference only.Payment Methods
Delivery Services
19.9V Clamp 181A Ipp Tvs Diode Surface Mount DO-218AB
Quick Inquiry
SM5S12AHE3-TP
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 12V |
| Voltage - Breakdown (Min) | 13.3V |
| Voltage - Clamping (Max) @ Ipp | 19.9V |
| Current - Peak Pulse (10/1000µs) | 181A |
| Power - Peak Pulse | 3600W (3.6kW) |
| Power Line Protection | No |
| Applications | - |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | DO-218AB |
| Supplier Device Package | DO-218AB |
| Base Product Number | - |
| Unidirectional Channels | 1 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | SM5S12AHE3/2D | SM5S12AHE3_A/I | SM5S12A-TP | SM5S12ATHE3/I |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Micro Commercial Co | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | TVS DIODE 12VWM 19.9VC DO218AB | TVS DIODE 12VWM 19.9VC DO218AB | Interface | TVS DIODE 12VWM 19.9VC DO218AC |
| Series | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Micro Commercial Co | Vishay General Semiconductor - Diodes Division |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Bulk | Tape & Reel (TR) |
