SMAJ33CA
lmages are for reference only.SMAJ33CA
TVS, BI-DIR, 400W, 33V, DO-214AC
DatasheetDO-214AC, SMA
60,640 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
53.3V Clamp 7.5A Ipp Tvs Diode Surface Mount DO-214AC (SMA)
SMAJ33CA
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Good-Ark Semiconductor |
| Series | SMAJx |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 33V |
| Voltage - Breakdown (Min) | 36.7V |
| Voltage - Clamping (Max) @ Ipp | 53.3V |
| Current - Peak Pulse (10/1000µs) | 7.5A |
| Power - Peak Pulse | 400W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | DO-214AC, SMA |
| Supplier Device Package | DO-214AC (SMA) |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
|
| Part Number | SMAJ33C | SMAJ33C | SMAJ33CA | SMAJ33CA |
| Manufacturer | Taiwan Semiconductor Corporation | Littelfuse Inc. | MDD | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 400W, 40.8V, 10%, BIDIRECTIONAL, | TVS DIODE 33VWM 55.97VC DO214AC | TVS DIODE 33VWM 53.3VC SMA | TVS DIODE 33VWM 53.3VC DO214AC |
| Series | Taiwan Semiconductor Corporation | Littelfuse Inc. | MDD | Taiwan Semiconductor Corporation |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
