SML-521MYWT86
lmages are for reference only.SML-521MYWT86
LED GRN/YLW DIFFUSED 1315 SMD
Datasheet0605 (1513 Metric)
89,975 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Green, Yellow LED Indication - Discrete 2.2V Green, 1.9V Yellow 0605 (1513 Metric)
SML-521MYWT86
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Green, Yellow |
| Configuration | Independent |
| Lens Color | White |
| Lens Transparency | Diffused |
| Millicandela Rating | 16mcd Green, 63mcd Yellow |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.10mm x 1.30mm |
| Voltage - Forward (Vf) (Typ) | 2.2V Green, 1.9V Yellow |
| Current - Test | 20mA Green, 20mA Yellow |
| Viewing Angle | - |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | - |
| Wavelength - Peak | 570nm Green, 590nm Yellow |
| Features | - |
| Package / Case | 0605 (1513 Metric) |
| Supplier Device Package | 1315 (0605) |
| Size / Dimension | 1.50mm L x 1.30mm W |
| Height (Max) | 0.70mm |
| Base Product Number | SML-521 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SML-521MDWT86 | SML-521MUWT86 | SML-010DTT86 | SML-010DTT87 |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED GRN/ORANGE DIFFUSED 1315 SMD | LED GREEN/RED DIFFUSED 1315 SMD | LED ORANGE CLEAR 3020 SMD | LED ORANGE CLEAR 3020 SMD |
| Series | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
