SMS3922-015LF
lmages are for reference only.SMS3922-015LF
RF DIODE SCHOTTKY 8V 75MW SOT143
DatasheetTO-253-4, TO-253AA
63,414 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Diode Schottky - 2 Independent 8V 50 mA 75 mW SOT-143
SMS3922-015LF
| Category | Discrete Semiconductor Products - Diodes - RF Diodes |
| Manufacturer | Skyworks Solutions Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | SMS3922-015 |
| Diode Type | Schottky - 2 Independent |
| Voltage - Peak Reverse (Max) | 8V |
| Current - Max | 50 mA |
| Capacitance @ Vr, F | - |
| Resistance @ If, F | - |
| Power Dissipation (Max) | 75 mW |
| Operating Temperature | 150°C (TJ) |
| Package / Case | TO-253-4, TO-253AA |
| Supplier Device Package | SOT-143 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SMS3922-001LF | SMS3922-004LF | SMS3922-040LF | SMS3922-079LF |
| Manufacturer | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RF DIODE SCHOTTKY 8V 75MW SOT23 | RF DIODE SCHOTTKY 8V 75MW SOT23 | RF DIODE SCHOTTKY 8V 75MW SOD882 | RF DIODE SCHOTTKY 8V 75MW SC79 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
