SN5472J
lmages are for reference only.SN5472J
AND-GATED J-K MASTER-SLAVE FLIP-
Datasheet14-CDIP (0.300", 7.62mm)
53,816 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 1 Element JK Type 1 Bit Positive Edge 14-CDIP (0.300", 7.62mm)
SN5472J
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Output Type | Complementary |
| Number of Elements | 1 |
| Number of Bits per Element | 1 |
| Clock Frequency | 20 MHz |
| Max Propagation Delay @ V, Max CL | 40ns @ 5V, 15pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 16mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 20 mA |
| Input Capacitance | - |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SN54107J | SN5476J | SN54ALS109AJ | SN54ALS174J |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | 54107 DUAL J-K FLIP-FLOPS WITH C | DUAL J-K FLIP-FLOPS WITH PRESET | 54ALS109A DUAL J-K POSITIVE-EDGE | HEX D-TYPE FLIP-FLOPS WITH CLEAR |
| Series | * | - | * | 54ALS |
| Packaging | Bulk | Tube | Bulk | Tube |
