SN74AUC1G66DBVRE4
lmages are for reference only.SN74AUC1G66DBVRE4
IC SWITCH SPST-NOX1 15OHM SOT23
DatasheetSC-74A, SOT-753
87,924 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 Circuit IC Switch 1:1 15Ohm SOT-23-5
SN74AUC1G66DBVRE4
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | Texas Instruments |
| Series | 74AUC |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 15Ohm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | 0.8V ~ 2.7V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 1.4ns, 1.5ns |
| -3db Bandwidth | 500MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 3.5pF |
| Current - Leakage (IS(off)) (Max) | 1µA |
| Crosstalk | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
| Base Product Number | 74AUC1G66 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | SN74AUC1G66DBVR | SN74AUC1G66DBVR | SN74AUC1G66DBVRE4 | SN74AUC1G66DCKR |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC SWITCH SPST-NOX1 15OHM SOT23 | IC SWITCH SPST-NOX1 15OHM SOT23 | IC SWITCH SPST-NOX1 15OHM SOT23 | IC SWITCH SPST-NOX1 15OHM SC70-5 |
| Series | 74AUC | 74AUC | 74AUC | 74AUC |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
