SN74HC682N
lmages are for reference only.SN74HC682N
IC COMPARATOR MAG 8BIT 20DIP
Datasheet20-DIP (0.300", 7.62mm)
51,361 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Magnitude Comparator Bit Active Low Output A=B, A>B 20-PDIP
SN74HC682N
| Category | Integrated Circuits (ICs) - Logic - Comparators |
| Manufacturer | Texas Instruments |
| Series | 74HC |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Magnitude Comparator |
| Number of Bits | 8 |
| Output | Active Low |
| Output Function | A=B, A>B |
| Voltage - Supply | 2V ~ 6V |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Max Propagation Delay @ V, Max CL | 47ns @ 6V, 50pF |
| Current - Quiescent (Iq) | - |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
| Mounting Type | Through Hole |
| Base Product Number | 74HC682 |
| Product Attribute |  |
 |
 |
 |
| Part Number | SN74HC682DW | SN74HC682DWR | SN74HC684DW | SN74HC684DWR |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC COMPARATOR MAG 8BIT 20SOIC | IC COMPARATOR MAG 8BIT 20SOIC | IC COMPARATOR MAG 8BIT 20SOIC | IC COMPARATOR MAG 8BIT 20SOIC |
| Series | 74HC | 74HC | 74HC | 74HC |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR) |
