SN74LS684NSR
lmages are for reference only.SN74LS684NSR
IC COMPARATOR MAG 8BIT 20SO
Datasheet20-SOIC (0.209", 5.30mm Width)
50,644 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Magnitude Comparator Bit Active Low Output A=B, A>B 20-SO
SN74LS684NSR
| Category | Integrated Circuits (ICs) - Logic - Comparators |
| Manufacturer | Texas Instruments |
| Series | 74LS |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Magnitude Comparator |
| Number of Bits | 8 |
| Output | Active Low |
| Output Function | A=B, A>B |
| Voltage - Supply | 4.85V ~ 5.25V |
| Current - Output High, Low | 400µA, 24mA |
| Max Propagation Delay @ V, Max CL | 30ns @ 5V, 45pF |
| Current - Quiescent (Iq) | - |
| Operating Temperature | 0°C ~ 70°C |
| Grade | - |
| Qualification | - |
| Package / Case | 20-SOIC (0.209", 5.30mm Width) |
| Supplier Device Package | 20-SO |
| Mounting Type | Surface Mount |
| Base Product Number | 74LS684 |
| Product Attribute |  |
 |
|
 |
| Part Number | SN74LS684NS | SN74LS684DW | SN74LS684DW | SN74LS684DWR |
| Manufacturer | Texas Instruments | Texas Instruments | onsemi | Texas Instruments |
| RoHS Status | Not applicable | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC COMPARATOR MAGNITUDE 20SO | IC COMPARATOR MAG 8BIT 20SOIC | IC COMPARATOR MAG 8BIT 20SOIC | IC COMPARATOR MAG 8BIT 20SOIC |
| Series | * | 74LS | 74LS | 74LS |
| Packaging | Bulk | Tube | Tube | Tape & Reel (TR) |
