SS0503EC-TR-H
Manufacturer
onsemiDescription
DIODE SCHOTTKY 30V 500MA 2ECSP
Datasheet
DatasheetPackage
2-UDFN
In Stock
41,857 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SS0503EC-TR-H
SS0503EC-TR-H
lmages are for reference only.Payment Methods
Delivery Services
Diode 30 V 500mA Surface Mount 2-ECSP1008
Quick Inquiry
SS0503EC-TR-H
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Current - Average Rectified (Io) | 500mA |
| Voltage - Forward (Vf) (Max) @ If | 560 mV @ 500 mA |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 10 ns |
| Current - Reverse Leakage @ Vr | 100 µA @ 15 V |
| Capacitance @ Vr, F | 6pF @ 10V, 1MHz |
| Mounting Type | Surface Mount |
| Package / Case | 2-UDFN |
| Supplier Device Package | 2-ECSP1008 |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Base Product Number | SS0503 |
| Grade | - |
| Qualification | - |
