SSL-LX25783AW-TD
lmages are for reference only.SSL-LX25783AW-TD
LED AMB DIFF RECT 2.3MMX7MM T/H
DatasheetRadial
58,284 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Amber LED Indication - Discrete 2V Radial
SSL-LX25783AW-TD
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Lumex Opto/Components Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Color | Amber |
| Configuration | Standard |
| Lens Color | White |
| Lens Transparency | Diffused |
| Millicandela Rating | 10mcd |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 7.00mm x 2.30mm |
| Voltage - Forward (Vf) (Typ) | 2V |
| Current - Test | 20mA |
| Viewing Angle | 110° |
| Mounting Type | Through Hole |
| Wavelength - Dominant | - |
| Wavelength - Peak | 605nm |
| Features | - |
| Package / Case | Radial |
| Supplier Device Package | Rectangular 2.3mmx7mm |
| Size / Dimension | - |
| Height (Max) | 8.00mm |
| Base Product Number | SSL-LX25783 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | SSL-LX25783AD | SSL-LX25783GD | SSL-LX25783ID | SSL-LX25783SRD |
| Manufacturer | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED AMB DIFF RECT 2.3MMX7MM T/H | LED GRN DIFF RECT 2.3MMX7MM T/H | LED RED DIFF RECT 2.3MMX7MM T/H | LED RED DIFF RECT 2.3MMX7MM T/H |
| Series | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. |
| Packaging | Bulk | Bulk | Bulk | Bulk |
