SSQE48S09120-NS0NG
lmages are for reference only.SSQE48S09120-NS0NG
DC DC CONVERTER 12V 108W
Datasheet5-SMD Module, 1/16 Brick
22,701 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 12V 9A 45V - 55V Input
SSQE48S09120-NS0NG
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Bel Power Solutions |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 45V |
| Voltage - Input (Max) | 55V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 9A |
| Power (Watts) | 108 W |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OCP, OTP, OVP, SCP, UVLO |
| Operating Temperature | -20°C ~ 70°C |
| Efficiency | 94.4% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 5-SMD Module, 1/16 Brick |
| Size / Dimension | 1.30" L x 0.90" W x 0.40" H (33.0mm x 22.8mm x 10.2mm) |
| Supplier Device Package | - |
| Control Features | Enable, Active Low |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | 500 V |
| Product Attribute |  |
 |
|
|
| Part Number | SSQE48S07120-NS0NG | SSQE48T07050-NAANG | SSQE48T07050-NABNG | SSQE48T07050-PABNG |
| Manufacturer | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 12V 84W | DC DC CONVERTER 5V 35W | DC DC CONVERTER 5V 35W | DC DC CONVERTER 5V 35W |
| Series | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| Packaging | Bulk | Bulk | Bulk | Bulk |
