STD9N80K5
lmages are for reference only.STD9N80K5
MOSFET N-CHANNEL 800V 7A DPAK
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
17,681 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 800 V 7A (Tc) 110W (Tc) Surface Mount DPAK
STD9N80K5
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | STMicroelectronics |
| Series | MDmesh™ K5 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 800 V |
| Current - Continuous Drain (Id) @ 25°C | 7A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 900mOhm @ 3.5A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 100µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 340 pF @ 100 V |
| FET Feature | - |
| Power Dissipation (Max) | 110W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DPAK |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Base Product Number | STD9 |
| Gate Charge (Qg) (Max) @ Vgs | 12 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | STD100N03LT4 | STD100N10F7 | STD100N10LF7AG | STD100N3LF3 |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 30V 80A DPAK | MOSFET N CH 100V 80A DPAK | MOSFET N-CH 100V 80A DPAK | MOSFET N-CH 30V 80A DPAK |
| Series | STripFET™ | DeepGATE™, STripFET™ VII | STripFET™ F7 | STripFET™ II |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
