Product CatalogPart Number
STGP10M65DF2
Manufacturer
STMicroelectronicsDescription
IGBT 650V 10A TO-220AB
Datasheet
DatasheetPackage
TO-220-3
In Stock
34,201 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
STGP10M65DF2
STGP10M65DF2
lmages are for reference only.Payment Methods
Delivery Services
IGBT Trench Field Stop 650 V 20 A 115 W Through Hole TO-220
Quick Inquiry
STGP10M65DF2
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 20 A |
| Current - Collector Pulsed (Icm) | 40 A |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 10A |
| Power - Max | 115 W |
| Switching Energy | 120µJ (on), 270µJ (off) |
| Input Type | Standard |
| Gate Charge | 28 nC |
| Td (on/off) @ 25°C | 19ns/91ns |
| Test Condition | 400V, 10A, 22Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220 |
| Reverse Recovery Time (trr) | 96 ns |
| Base Product Number | STGP10 |
