Product CatalogPart Number
STGW100H65FB2-4
Manufacturer
STMicroelectronicsDescription
TRENCH GATE FIELD-STOP, 650 V, 1
Datasheet
DatasheetPackage
TO-247-4
In Stock
74,168 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
STGW100H65FB2-4
STGW100H65FB2-4
lmages are for reference only.Payment Methods
Delivery Services
IGBT Trench Field Stop 650 V 145 A 441 W Through Hole TO-247-4
Quick Inquiry
STGW100H65FB2-4
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | STMicroelectronics |
| Series | HB2 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 145 A |
| Current - Collector Pulsed (Icm) | 300 A |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 100A |
| Power - Max | 441 W |
| Switching Energy | 1.06mJ (on), 1.14mJ (off) |
| Input Type | Standard |
| Gate Charge | 288 nC |
| Td (on/off) @ 25°C | 23ns/141ns |
| Test Condition | 400V, 100A, 3.3Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-4 |
| Supplier Device Package | TO-247-4 |
| Reverse Recovery Time (trr) | - |
| Base Product Number | STGW100 |
Parts with Similar Specifications
| Product Attribute |  |
|
 |
 |
| Part Number | STGW10M65DF2 | STGW15H120DF2 | STGW15H120F2 | STGW15M120DF3 |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRENCH GATE FIELD-STOP IGBT M SE | IGBT H-SERIES 1200V 15A TO-247 | IGBT H-SERIES 1200V 15A TO-247 | IGBT 1200V 30A 259W |
| Series | M | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
