Half Bridge (3) Driver AC Motors IGBT 29-SIP
STK551U3A2A-E
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge (3) |
| Applications | AC Motors |
| Interface | Logic |
| Load Type | Inductive |
| Technology | IGBT |
| Rds On (Typ) | - |
| Current - Output / Channel | 20A |
| Current - Peak Output | 40A |
| Voltage - Supply | 12.5V ~ 17.5V |
| Voltage - Load | 450V (Max) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Features | Bootstrap Circuit, Latch Function, Status Flag |
| Fault Protection | Current Limiting, Shoot-Through, UVLO |
| Mounting Type | Through Hole |
| Package / Case | 29-SSIP Module, 21 Leads, Formed Leads |
| Supplier Device Package | 29-SIP |
| Base Product Number | STK551 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | STK551U3A2A-E | STK551U362A-E | STK551U362A-E | STK551U392A-E |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC HALF BRIDGE DRIVER 20A 29SIP | IC HALF BRIDGE DRIVER 10A 29SIP | IC HALF BRIDGE DRIVER 10A 29SIP | IC HALF BRIDGE DRIVER 15A 29SIP |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
