Product CatalogPart Number
STL76DN4LF7AG
Manufacturer
STMicroelectronicsDescription
MOSFET 2N-CH 40V 40A POWERFLAT
Datasheet
DatasheetPackage
8-PowerVDFN
In Stock
28,623 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
STL76DN4LF7AG
STL76DN4LF7AG
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 40V 40A (Tc) 71W (Tc) Surface Mount PowerFlat™ (5x6)
Quick Inquiry
STL76DN4LF7AG
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | STMicroelectronics |
| Series | STripFET™ F7 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 40V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Tc) |
| Rds On (Max) @ Id, Vgs | 6mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 956pF @ 25V |
| Power - Max | 71W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVDFN |
| Supplier Device Package | PowerFlat™ (5x6) |
| Base Product Number | STL76 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
