STLD20CP1PQR
lmages are for reference only.STLD20CP1PQR
IC LED DRV RGLTR PWM 300MA 16QFN
Datasheet16-VFQFN Exposed Pad
76,735 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 2 Output DC DC Regulator Step-Up (Boost), Switched Capacitor (Charge Pump) PWM, Single-Wire Dimming 300mA (Flash) 16-QFN (3x3)
STLD20CP1PQR
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost), Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 2 |
| Voltage - Supply (Min) | 2.8V |
| Voltage - Supply (Max) | 6V |
| Voltage - Output | 17V |
| Current - Output / Channel | 300mA (Flash) |
| Frequency | 1.3MHz |
| Dimming | PWM, Single-Wire |
| Applications | Backlight, Camera Flash |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Supplier Device Package | 16-QFN (3x3) |
| Base Product Number | STLD20 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | STLD20D-C8 | STLD20D-DEF | STP16CPC05XTTR | STP16CL596XTTR |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV RGLTR PWM SOT23-8 | IC LED DRVR RGLTR PWM 21MA 8QFN | IC LED DRVR LINEAR 100MA 24TSSOP | IC LED DRVR LINEAR 90MA 24TSSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
