STPS30SM60CR
lmages are for reference only.STPS30SM60CR
DIODE ARRAY SCHOTT 60V 15A I2PAK
DatasheetTO-262-3 Long Leads, I2PAK, TO-262AA
45,012 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Diode Array 1 Pair Common Cathode 60 V 15A Through Hole TO-262-3 Long Leads, I2PAK, TO-262AA
STPS30SM60CR
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Diode Configuration | 1 Pair Common Cathode |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Current - Average Rectified (Io) (per Diode) | 15A |
| Voltage - Forward (Vf) (Max) @ If | 625 mV @ 15 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 65 µA @ 60 V |
| Operating Temperature - Junction | 150°C (Max) |
| Mounting Type | Through Hole |
| Package / Case | TO-262-3 Long Leads, I2PAK, TO-262AA |
| Supplier Device Package | I2PAK |
| Base Product Number | STPS30 |
| Reverse Recovery Time (trr) | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | STPS30SM60CG-TR | STPS30SM60CT | STPS30120CR | STPS30120CT |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE ARRAY SCHOTT 60V 15A D2PAK | DIODE ARRAY SCHOT 60V 15A TO-220 | DIODE ARRAY SCHOT 120V 15A I2PAK | DIODE ARR SCHOTT 120V 15A TO-220 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube | Tube |
