STSPIN233
lmages are for reference only.STSPIN233
IC HALF BRIDGE DRV 1.3A 16VFQFPN
Datasheet16-VFQFN Exposed Pad
45,142 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge (3) Driver DC Motors, General Purpose Power MOSFET 16-VFQFPN (3x3)
STSPIN233
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | STMicroelectronics |
| Series | STSPIN2 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge (3) |
| Applications | DC Motors, General Purpose |
| Interface | Logic |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | 400mOhm LS + HS |
| Current - Output / Channel | 1.3A |
| Current - Peak Output | - |
| Voltage - Supply | 0V ~ 5V |
| Voltage - Load | 1.8V ~ 10V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Features | - |
| Fault Protection | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Supplier Device Package | 16-VFQFPN (3x3) |
| Base Product Number | STSPIN233 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | STSPIN230 | STSPIN230 | STSPIN233 | STSPIN240 |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC HALF BRIDGE DRV 1.3A 16VFQFPN | IC HALF BRIDGE DRV 1.3A 16VFQFPN | IC HALF BRIDGE DRV 1.3A 16VFQFPN | IC HALF BRIDGE DRV 1.3A 16VFQFPN |
| Series | STSPIN2 | STSPIN2 | STSPIN2 | STSPIN2 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
