Product CatalogPart Number
SZESD7102BT1G
Manufacturer
onsemiDescription
TVS DIODE 5VWM 30VC SC75 SOT416
Datasheet
DatasheetPackage
SC-75, SOT-416
In Stock
32,265 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SZESD7102BT1G
SZESD7102BT1G
lmages are for reference only.Payment Methods
Delivery Services
30V (Typ) Clamp 16A Ipp Tvs Diode Surface Mount SC-75, SOT-416
Quick Inquiry
SZESD7102BT1G
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Steering (Rail to Rail) |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5V |
| Voltage - Breakdown (Min) | 16.5V |
| Voltage - Clamping (Max) @ Ipp | 30V (Typ) |
| Current - Peak Pulse (10/1000µs) | 16A |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | - |
| Capacitance @ Frequency | 0.3pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-75, SOT-416 |
| Supplier Device Package | SC-75, SOT-416 |
| Base Product Number | SZESD7102 |
| Unidirectional Channels | 2 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
