TAS5100ADAP
lmages are for reference only.TAS5100ADAP
IC AMP CLASS D MONO 30W 32HTSSOP
Datasheet32-PowerTSSOP (0.240", 6.10mm Width)
73,465 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Amplifier IC 1-Channel (Mono) Class D 32-HTSSOP
TAS5100ADAP
| Category | Integrated Circuits (ICs) - Linear - Amplifiers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Class D |
| Output Type | 1-Channel (Mono) |
| Max Output Power x Channels @ Load | 30W x 1 @ 8Ohm |
| Voltage - Supply | 3V ~ 3.6V |
| Features | Digital Inputs, Mute, Short-Circuit and Thermal Protection, Shutdown |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Supplier Device Package | 32-HTSSOP |
| Package / Case | 32-PowerTSSOP (0.240", 6.10mm Width) |
| Base Product Number | TAS5100 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TAS5100AIDAP | TAS5100DAP | TAS5101DAP | TAS5101DAPR |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | AUDIO AMPLIFIER, 2 CHANNEL(S) | IC AMP AUDIO PWR 30W D 32HTSSOP | IC AMP CLASS D STER 15W 32HTSSOP | IC AMP CLASS D STER 15W 32HTSSOP |
| Series | - | - | Equibit™ | Equibit™ |
| Packaging | Bulk | Tube | Tube | Tape & Reel (TR) |
