TB9061AFNG,EL
lmages are for reference only.TB9061AFNG,EL
AUTOMOTIVE BLDC MOTOR CONTROLLER
Datasheet24-LSSOP (0.220", 5.60mm Width)
29,983 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Motor Driver Bi-CMOS Parallel 24-SSOP
TB9061AFNG,EL
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Function | Controller - Commutation, Direction Management |
| Output Configuration | Half Bridge (3) |
| Interface | Parallel |
| Technology | Bi-CMOS |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | - |
| Voltage - Supply | 5.5V ~ 18V |
| Voltage - Load | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 24-LSSOP (0.220", 5.60mm Width) |
| Supplier Device Package | 24-SSOP |
| Base Product Number | TB9061 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute | |
 |
|
 |
| Part Number | TB9061AFNG,EL | TB9051FTG,EL | TB9051FTG,EL | TB9052FNG(EL) |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | |
| Description | AUTOMOTIVE BLDC MOTOR CONTROLLER | MOTOR CONTROLLER SINGLE CHANNEL | MOTOR CONTROLLER SINGLE CHANNEL | AUTOMOTIVE H-BRIDGE DRIVER |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
