TC1044SCOA713
lmages are for reference only.TC1044SCOA713
IC REG CHARGE PUMP 20MA 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
64,967 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Charge Pump Switching Regulator IC Negative Fixed -Vin 1 Output 20mA 8-SOIC (0.154", 3.90mm Width)
TC1044SCOA713
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Function | Ratiometric |
| Output Configuration | Negative |
| Topology | Charge Pump |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 1.5V |
| Voltage - Input (Max) | 12V |
| Voltage - Output (Min/Fixed) | -Vin |
| Voltage - Output (Max) | - |
| Current - Output | 20mA |
| Frequency - Switching | 10kHz, 45kHz |
| Synchronous Rectifier | No |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | TC1044 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TC1044SCOA | TC1044SCPA | TC1044SEOA | TC1044SEOA713 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CHARGE PUMP 20MA 8SOIC | IC REG CHARGE PUMP 20MA 8PDIP | IC REG CHARGE PUMP 20MA 8SOIC | IC REG CHARGE PUMP 20MA 8SOIC |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
