TC74VHC393FT(EL,M)
lmages are for reference only.TC74VHC393FT(EL,M)
IC BIN COUNTER DL 4BIT 14TSSOP
Datasheet14-TSSOP (0.173", 4.40mm Width)
49,830 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Counter IC Binary Counter 2 Element 4 Bit Negative Edge 14-TSSOP
TC74VHC393FT(EL,M)
| Category | Integrated Circuits (ICs) - Logic - Counters-Dividers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | TC74VHC |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT)--> |
| RoHS Status | |
| Base Product Number | 74VHC393 |
| Logic Type | Binary Counter |
| Direction | Up |
| Number of Elements | 2 |
| Number of Bits per Element | 4 |
| Reset | Asynchronous |
| Timing | - |
| Count Rate | 170 MHz |
| Trigger Type | Negative Edge |
| Voltage - Supply | 2 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
.jpg "TC74HC4040AF(EL,F)") |
.jpg "TC74HC590AP(F)") |
 |
| Part Number | TC74HC393AF | TC74HC4040AF(EL,F) | TC74HC590AP(F) | TC74HC592APF |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | RoHS Compliant | |||
| Description | IC BINARY COUNTR DL 4BIT 14SOIC | IC BINARY COUNTER 12-BIT 16SOP | IC BINARY COUNTER 8-BIT 16DIP | IC BINARY COUNTER 8-BIT 16DIP |
| Series | 74HC | 74HC | 74HC | 74HC |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT)--> | Tube | Tube |
