TC7SH32FS,L3F
lmages are for reference only.TC7SH32FS,L3F
IC GATE OR 1CH 2-INP FSV
DatasheetSOT-953
31,365 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
OR Gate IC 1 Channel fSV
TC7SH32FS,L3F
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | TC7SH |
| Packaging | Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Base Product Number | 7SH32 |
| Logic Type | OR Gate |
| Number of Circuits | 1 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Max) | 2 µA |
| Current - Output High, Low | 8mA, 8mA |
| Input Logic Level - Low | 0.5V |
| Input Logic Level - High | 1.5V |
| Max Propagation Delay @ V, Max CL | 7.5ns @ 5V, 50pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | fSV |
| Package / Case | SOT-953 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TC7SH32F,LJ(CT | TC7SH32FU,LJ(CT | TC74AC00FTEL | TC74AC00PF |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | IC GATE OR 1CH 2-INP SMV | IC GATE OR 1CH 2-INP 5SSOP | IC GATE NAND 4CH 2-INP 14TSSOP | IC GATE NAND 4CH 2-INP 14DIP |
| Series | TC7SH | TC7SH | 74AC | 74AC |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube |
