TCR15AG10,LF
lmages are for reference only.TCR15AG10,LF
IC REG LINEAR 1V 1.5A 6WCSPF
Datasheet6-XFBGA, WLCSP
39,310 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 1.5A 6-WCSPF (0.80x1.2)
TCR15AG10,LF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | TCR15AG |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.228V @ 1.5A |
| Current - Output | 1.5A |
| Current - Quiescent (Iq) | 40 µA |
| PSRR | 95dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 85°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 6-XFBGA, WLCSP |
| Supplier Device Package | 6-WCSPF (0.80x1.2) |
| Base Product Number | TCR15AG10 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TCR15AG105,LF | TCR15AG09,LF | TCR15AG11,LF | TCR15AG12,LF |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | RoHS Compliant | RoHS non-compliant |
| Description | IC REG LINEAR 1.05V 1.5A 6WCSP | IC REG LINEAR 0.9V 1.5A 6WCSP | IC REG LINEAR 1.1V 1.5A 6WCSP | IC REG LINEAR 1.2V 1.5A 6WCSPF |
| Series | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
