TCR8BM10A,L3F
lmages are for reference only.TCR8BM10A,L3F
IC REG LINEAR 1V 800MA 5DFNB
Datasheet4-XDFN Exposed Pad
46,484 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 800mA 5-DFNB (1.2x1.2)
TCR8BM10A,L3F
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | TCR8BM |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.23V @ 800mA |
| Current - Output | 800mA |
| Current - Quiescent (Iq) | 36 µA |
| PSRR | 98dB (1kHz) |
| Control Features | Current Limit, Enable |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-XDFN Exposed Pad |
| Supplier Device Package | 5-DFNB (1.2x1.2) |
| Base Product Number | TCR8BM10 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TCR8BM10,L3F | TCR8BM105,L3F | TCR8BM105A,L3F | TCR8BM11,L3F |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 1V 800MA 5DFNB | IC REG LINEAR 1.05V 800MA 5DFNB | IC REG LINEAR 1.05V 800MA 5DFNB | IC REG LINEAR 1.1V 800MA 5DFNB |
| Series | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
