TFA9842AJ/N1,112
lmages are for reference only.TFA9842AJ/N1,112
IC AMP CLASS AB STER 7.5W 9PDBS
Datasheet9-SIP Exposed Tab, Formed Leads
14,580 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Amplifier IC 2-Channel (Stereo) Class AB 9-DBSP
TFA9842AJ/N1,112
| Category | Integrated Circuits (ICs) - Linear - Amplifiers |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Class AB |
| Output Type | 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 7.5W x 2 @ 4Ohm |
| Voltage - Supply | 9V ~ 28V |
| Features | Depop, Mute, Short-Circuit and Thermal Protection, Standby, Volume Control |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 9-DBSP |
| Package / Case | 9-SIP Exposed Tab, Formed Leads |
| Base Product Number | TFA984 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TFA9841J/N1,112 | TFA9842BJ/N1,112 | TFA9842J/N1,112 | TFA9843AJ/N1,112 |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC AMP CLASS AB MONO 7.5W 9PDBS | IC AMP CLASS AB STER 7.5W 9PDBS | IC AMP AB MONO/STEREO 15W 9PDBS | IC AMP CLASS AB STEREO 14W 9PDBS |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
