TK110E65Z,S1X
lmages are for reference only.TK110E65Z,S1X
650V DTMOS VI TO-220 110MOHM
DatasheetTO-220-3
80,073 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 650 V 24A (Ta) 190W (Tc) Through Hole TO-220
TK110E65Z,S1X
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 650 V |
| Current - Continuous Drain (Id) @ 25°C | 24A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 110mOhm @ 12A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 1.02mA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 2250 pF @ 300 V |
| FET Feature | - |
| Power Dissipation (Max) | 190W (Tc) |
| Operating Temperature | 150°C |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220 |
| Package / Case | TO-220-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 40 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | TK100A06N1,S4X | TK100A08N1,S4X | TK100A10N1,S4X | TK100E06N1,S1X |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 60V 100A TO220SIS | MOSFET N-CH 80V 100A TO220SIS | MOSFET N-CH 100V 100A TO220SIS | MOSFET N CH 60V 100A TO-220 |
| Series | U-MOSVIII-H | U-MOSVIII-H | U-MOSVIII-H | U-MOSVIII-H |
| Packaging | Tube | Tube | Tube | Tube |
