TLP3823(LF5,F
lmages are for reference only.TLP3823(LF5,F
SSR RELAY SPST-NO 3A 0-100V
Datasheet8-SMD, Gull Wing
16,834 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Solid State SPST-NO (1 Form A) 8-SMD, Gull Wing
TLP3823(LF5,F
| Category | Relays - Solid State Relays SSR - |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | TLP3823 |
| Packaging | Tube |
| RoHS Status | |
| Mounting Type | Surface Mount |
| Circuit | SPST-NO (1 Form A) |
| Output Type | AC, DC |
| Voltage - Input | 1.64VDC |
| Voltage - Load | 0 V ~ 100 V |
| Load Current | 3 A |
| Termination Style | Gull Wing |
| Operating Temperature | -40°C ~ 110°C |
| Package / Case | 8-SMD, Gull Wing |
| Supplier Device Package | 8-SMD |
| Approval Agency | cUL, UL |
| Grade | - |
| Qualification | - |
| Base Product Number | TLP382 |
| On-State Resistance (Max) | 150 mOhms |
| Product Attribute |  |
 |
 |
 |
| Part Number | TLP3823(LF1,F | TLP3823(F | TLP3823(TP1,F | TLP3823(TP5,F |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | |
| Description | SSR RELAY SPST-NO 3A 0-100V | SSR RELAY SPST-NO 3A 0-100V | SSR RELAY SPST-NO 3A 0-100V | SSR RELAY SPST-NO 3A 0-100V |
| Series | TLP3823 | TLP3823 | TLP3823 | TLP3823 |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
