TLVR100512-R12L-D01
lmages are for reference only.TLVR100512-R12L-D01
IND 120NH 0.45MOHM 64A
DatasheetNonstandard
81,143 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
120 nH Unshielded Molded Inductor 75 A 0.125mOhm Nonstandard
TLVR100512-R12L-D01
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TAI-TECH Advanced Electronics Co., Ltd. |
| Series | TLVR100512-D01 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Molded |
| Material - Core | - |
| Inductance | 120 nH |
| Tolerance | ±15% |
| Current Rating (Amps) | 75 A |
| Current - Saturation (Isat) | 74A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 0.125mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.394" L x 0.197" W (10.00mm x 5.00mm) |
| Height - Seated (Max) | 0.472" (12.00mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
|
| Part Number | TLVR100512-R10L-D01 | TLVR100512-R15L-D01 | TLVR100512-R17L-D01 | TLVR100512-R07L-D01 |
| Manufacturer | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IND 100NH 0.45MOHM 77A | IND 150NH 0.45MOHM 51A | IND 170NH 0.45MOHM 45A | IND 70NH 0.45MOHM 110A |
| Series | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. | TAI-TECH Advanced Electronics Co., Ltd. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
