TOP209GN-TL
lmages are for reference only.TOP209GN-TL
IC OFFLINE SWITCH FLYBACK 8SMD
Datasheet8-SMD, Gull Wing
34,376 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 70kHz 8-SMD
TOP209GN-TL
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Power Integrations |
| Series | TOPSwitch® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 67% |
| Frequency - Switching | 70kHz |
| Power (Watts) | 2 W |
| Fault Protection | Current Limiting, Over Temperature |
| Control Features | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 8-SMD, Gull Wing |
| Supplier Device Package | 8-SMD |
| Mounting Type | Surface Mount |
| Base Product Number | TOP209 |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TOP209GN | TOP200YAI | TOP200YN | TOP201YAI |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ||
| Description | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SW MULT TOP TO220-3 | IC OFFLINE SW MULT TOP TO220-3 | IC OFFLINE SW MULT TOP TO220-3 |
| Series | TOPSwitch® | TOPSwitch® | TOPSwitch® | TOPSwitch® |
| Packaging | Tube | Tube | Tube | Tube |
