TOP234Y
lmages are for reference only.TOP234Y
IC OFFLINE SW FLYBACK TO220-7B
DatasheetTO-220-7 Formed Leads, 5 Leads
28,485 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 66kHz ~ 132kHz TO-220-7B
TOP234Y
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Power Integrations |
| Series | TOPSwitch®-FX |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 78% |
| Frequency - Switching | 66kHz ~ 132kHz |
| Power (Watts) | 75 W |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage |
| Control Features | Frequency Control |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | TO-220-7 Formed Leads, 5 Leads |
| Supplier Device Package | TO-220-7B |
| Mounting Type | Through Hole |
| Base Product Number | TOP234 |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TOP234G | TOP234G-TL | TOP234GN | TOP234GN-TL |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS Compliant | RoHS Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SWITCH FLYBACK 8SMD |
| Series | TOPSwitch®-FX | TOPSwitch®-FX | TOPSwitch®-FX | TOPSwitch®-FX |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
