TOP271EG
lmages are for reference only.TOP271EG
IC OFFLINE SWITCH FLYBACK 7ESIP
Datasheet7-SSIP, 6 Leads, Exposed Pad, Formed Leads
28,515 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 66kHz, 132kHz eSIP-7C
TOP271EG
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Power Integrations |
| Series | TOPSwitch®-JX |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 725V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 78% |
| Frequency - Switching | 66kHz, 132kHz |
| Power (Watts) | 244 W |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit |
| Control Features | Frequency Control |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads |
| Supplier Device Package | eSIP-7C |
| Mounting Type | Through Hole |
| Base Product Number | TOP271 |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TOP270EG | TOP270KG-TL | TOP270VG | TOP271KG |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 7ESIP | IC OFFLINE SWITCH FLYBACK 12ESOP | IC OFFLINE SWITCH FLYBACK 12EDIP | IC OFFLINE SWITCH FLYBACK 12ESOP |
| Series | TOPSwitch®-JX | TOPSwitch®-JX | TOPSwitch®-JX | TOPSwitch®-JX |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube |
