TPAL0263F15R0K9
lmages are for reference only.Payment Methods
Delivery Services
15 Ohms ±1% 35W Chip Resistor TO-263-3, D2PAK (2 Leads + Tab), TO-263AB Automotive AEC-Q200, Non-Inductive Thick Film
TPAL0263F15R0K9
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | RESI |
| Series | TPAL0263 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Resistance | 15 Ohms |
| Tolerance | ±1% |
| Power (Watts) | 35W |
| Composition | Thick Film |
| Features | Automotive AEC-Q200, Non-Inductive |
| Temperature Coefficient | ±100ppm/°C |
| Operating Temperature | -55°C ~ 150°C |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263 |
| Ratings | AEC-Q200 |
| Size / Dimension | 0.398" L x 0.307" W (10.10mm x 7.80mm) |
| Height - Seated (Max) | 0.189" (4.80mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPAL0263F100RK9 | TPAL0263F10K0K9 | TPAL0263F10R0K9 | TPAL0263F1K00K9 |
| Manufacturer | RESI | RESI | RESI | RESI |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES 100 OHMS 35W 1% TO263 | RES 10K OHMS 35W 1% TO263 | RES 10 OHMS 35W 1% TO263 | RES 1K OHMS 35W 1% TO263 |
| Series | RESI | RESI | ||
| Packaging | Tube | Tube |
