TPD4163K,F
lmages are for reference only.TPD4163K,F
600V; IPD; 1A; HDIP30 INTELLIGEN
Datasheet30-PowerDIP Module
65,414 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Multiphase Motor Driver IGBT PWM 30-HDIP
TPD4163K,F
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Multiphase |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (3) |
| Interface | PWM |
| Technology | IGBT |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1A |
| Voltage - Supply | 13.5V ~ 16.5V |
| Voltage - Load | 50V ~ 450V |
| Operating Temperature | -40°C ~ 135°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 30-PowerDIP Module |
| Supplier Device Package | 30-HDIP |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | TPD4163F,LF | TPD4163F,LF | TPD4163K,F | TPD4162F,LF |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | 600V; IPD; 1A; HSSOP31 | 600V; IPD; 1A; HSSOP31 | 600V; IPD; 1A; HDIP30 INTELLIGEN | PB-F IPD IC HSSOP31 VBB(V)=600V |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
