TPIC46L02DB
lmages are for reference only.TPIC46L02DB
IC GATE DRVR LOW-SIDE 28SSOP
Datasheet28-SSOP (0.209", 5.30mm Width)
22,919 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Low-Side Gate Driver IC Non-Inverting 28-SSOP
TPIC46L02DB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Low-Side |
| Channel Type | Independent |
| Number of Drivers | 6 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4.5V ~ 5.5V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 1.2mA, 1.2mA |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 3.5µs, 3µs |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 28-SSOP |
| Base Product Number | TPIC46L02 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPIC46L02DBG4 | TPIC46L02DBLE | TPIC46L02DBR | TPIC46L02DBRG4 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | Not applicable | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE DRVR LOW-SIDE 28SSOP | LOW SIDE PRE FET DRIVER | IC GATE DRVR LOW-SIDE 28SSOP | IC GATE DRVR LOW-SIDE 28SSOP |
| Series | - | * | - | - |
| Packaging | Tube | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
