TPL810F30-3TR
lmages are for reference only.Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 180mA SOT-23-3
TPL810F30-3TR
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | 3PEAK |
| Series | TPL810 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 24V |
| Voltage - Output (Min/Fixed) | 3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.8V @ 180mA |
| Current - Output | 180mA |
| Current - Quiescent (Iq) | 5 µA |
| PSRR | 75dB ~ 65dB (100Hz ~ 10kHz) |
| Control Features | Current Limit |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| Base Product Number | - |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPL810F28-89TR | TPL810F33-3TR | TPL810F33-5TR | TPL810F33-89TR |
| Manufacturer | 3PEAK | 3PEAK | 3PEAK | 3PEAK |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LINEAR VOLTAGE REGULATOR IC FIXE | LINEAR VOLTAGE REGULATOR IC FIXE | LINEAR VOLTAGE REGULATOR IC FIXE | LINEAR VOLTAGE REGULATOR IC FIXE |
| Series | 3PEAK | 3PEAK | 3PEAK | 3PEAK |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
