TPS2042AD
lmages are for reference only.TPS2042AD
IC PWR SWITCH N-CHAN 1:2 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
94,852 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 500mA 8-SOIC
TPS2042AD
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Rds On (Typ) | 80mOhm |
| Input Type | Inverting |
| Features | - |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
| Operating Temperature | 0°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOIC |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Base Product Number | TPS2042 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPS2042ADG4 | TPS2042ADR | TPS2042ADRG4 | TPS2041AD |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC PWR SWITCH N-CHAN 1:2 8SOIC | IC PWR SWITCH N-CHAN 1:2 8SOIC | IC PWR SWITCH N-CHAN 1:2 8SOIC | IC PWR SWITCH N-CHAN 1:1 8SOIC |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube |
