Low-Side Gate Driver IC Inverting, Non-Inverting 8-TSSOP
TPS2813PW
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Low-Side |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4V ~ 14V |
| Logic Voltage - VIL, VIH | 1V, 4V |
| Current - Peak Output (Source, Sink) | 2A, 2A |
| Input Type | Inverting, Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 14ns, 15ns |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 8-TSSOP |
| Base Product Number | TPS2813 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPS2813P | TPS2813PE4 | TPS2813PWG4 | TPS2813PWLE |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | |
| Description | IC GATE DRVR LOW-SIDE 8DIP | NAND GATE BASED MOSFET DRIVER, 2 | IC GATE DRVR LOW-SIDE 8TSSOP | NAND GATE BASED MOSFET DRIVER |
| Series | - | - | - | - |
| Packaging | Tube | Bulk | Tube | Bulk |
