TPS7201QD
lmages are for reference only.TPS7201QD
IC REG LIN POS ADJ 250MA 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
35,144 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 250mA 8-SOIC
TPS7201QD
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 10V |
| Voltage - Output (Min/Fixed) | 1.2V |
| Voltage - Output (Max) | 9.75V |
| Voltage Dropout (Max) | 0.2V @ 350mA |
| Current - Output | 250mA |
| Current - Quiescent (Iq) | 80 µA |
| PSRR | 85dB ~ 50dB (10Hz ~ 1MHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | TPS7201 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPS7201QDR | TPS7201QDRG4 | TPS7201QP | TPS7201QPW |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LIN POS ADJ 250MA 8SOIC | IC REG LIN POS ADJ 250MA 8SOIC | IC REG LINEAR POS ADJ 250MA 8DIP | IC REG LIN POS ADJ 250MA 8TSSOP |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube | Tube |
