TPS77701D
lmages are for reference only.TPS77701D
IC REG LIN POS ADJ 750MA 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
82,852 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 750mA 8-SOIC
TPS77701D
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 10V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | 5.5V |
| Voltage Dropout (Max) | - |
| Current - Output | 750mA |
| Current - Quiescent (Iq) | 125 µA |
| PSRR | 60dB (1kHz) |
| Control Features | Enable, Power Good, Reset |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | TPS77701 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPS77701DR | TPS77701PWP | TPS77701PWPR | TPS77701PWPRG4 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LIN POS ADJ 750MA 8SOIC | IC REG LIN POS ADJ 20HTSSOP | IC REG LIN POS ADJ 20HTSSOP | IC REG LIN POS ADJ 20HTSSOP |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
