TSM300NB06LDCR
lmages are for reference only.TSM300NB06LDCR
MOSFET 2N-CH 60V 5A 8PDFNU
Datasheet8-PowerTDFN
48,175 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 60V 5A (Ta), 24A (Tc) 2W (Ta), 40W (Tc) Surface Mount 8-PDFNU (5x6)
TSM300NB06LDCR
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 5A (Ta), 24A (Tc) |
| Rds On (Max) @ Id, Vgs | 30mOhm @ 5A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 966pF @ 30V |
| Power - Max | 2W (Ta), 40W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Supplier Device Package | 8-PDFNU (5x6) |
| Base Product Number | TSM300 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TSM300NB06DCR RLG | TSM300NB06LDCR RLG | TSM3911DCX6 | TSM3911DCX6 RFG |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2N-CH 60V 6A 8PDFN | MOSFET 2N-CH 60V 5A 8PDFNU | MOSFET 2P-CH 20V 2.2A SOT26 | MOSFET 2P-CH 20V 2.2A SOT26 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
