P-Channel 60 V 20A (Tc) Surface Mount TO-252 (DPAK)
TSM480P06CP
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 48mOhm @ 8A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1250 pF @ 30 V |
| FET Feature | - |
| Power Dissipation (Max) | - |
| Operating Temperature | -50°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-252 (DPAK) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Base Product Number | TSM480 |
| Gate Charge (Qg) (Max) @ Vgs | 22.4 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | TSM480P06CH | TSM480P06CH X0G | TSM480P06CI C0G | TSM480P06CP ROG |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | -60V, -20A, SINGLE P-CHANNEL POW | MOSFET P-CHANNEL 60V 20A TO251 | MOSFET P-CH 60V 20A ITO220 | MOSFET P-CHANNEL 60V 20A TO252 |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
