TSM4NB60CI
lmages are for reference only.TSM4NB60CI
600V, 4A, SINGLE N-CHANNEL POWER
DatasheetTO-220-3 Full Pack, Isolated Tab
15,690 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 600 V 4A (Tc) 25W (Tc) Through Hole ITO-220
TSM4NB60CI
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 4A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 2.5Ohm @ 2A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 500 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 25W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | ITO-220 |
| Package / Case | TO-220-3 Full Pack, Isolated Tab |
| Base Product Number | TSM4 |
| Gate Charge (Qg) (Max) @ Vgs | 14.5 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | TSM4NB60CH | TSM4NB60CH C5G | TSM4NB60CI C0G | TSM4NB60CP |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 600V, 4A, SINGLE N-CHANNEL POWER | MOSFET N-CH 600V 4A TO251 | MOSFET N-CH 600V 4A ITO220AB | 600V, 4A, SINGLE N-CHANNEL POWER |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR) |
