Product CatalogPart Number
UC2710N
Manufacturer
UnitrodeDescription
UC2710 COMPLEMENTARY HIGH CURREN
Datasheet
DatasheetPackage
8-DIP (0.300", 7.62mm)
In Stock
24,831 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UC2710N
UC2710N
lmages are for reference only.Payment Methods
Delivery Services
Low-Side Gate Driver IC Inverting, Non-Inverting 8-PDIP
Quick Inquiry
UC2710N
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Unitrode |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 4.7V ~ 18V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | 6A, 6A |
| Input Type | Inverting, Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 85ns, 85ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| Base Product Number | UC2710 |
| Grade | - |
| Qualification | - |
