UC2827N-1
lmages are for reference only.UC2827N-1
IC REG CTRLR MULT TOPOLOGY 24DIP
Datasheet24-DIP (0.600", 15.24mm)
73,103 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Full-Bridge, Push-Pull Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 24-PDIP
UC2827N-1
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Full-Bridge, Push-Pull |
| Number of Outputs | 3 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 20V |
| Frequency - Switching | 220kHz |
| Duty Cycle (Max) | 91% |
| Synchronous Rectifier | Yes |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Frequency Control, Ramp, Soft Start |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 24-DIP (0.600", 15.24mm) |
| Supplier Device Package | 24-PDIP |
| Base Product Number | UC2827 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | UC2827N-1G4 | UC2827DW-1 | UC2827DW-2 | UC2827DW-2 |
| Manufacturer | Texas Instruments | Texas Instruments | Unitrode | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC REG CTRLR MULT TOPOLOGY 24DIP | IC REG CTRLR MULT TOP 24SOIC | UC2827-2 BUCK CURRENT/VOLTAGE FE | IC REG CTRLR MULT TOP 24SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tube |
