Product CatalogPart Number
UC2842DW
Manufacturer
UnitrodeDescription
1A, 500KHZ BIPOLAR, PDSO16
Datasheet
DatasheetPackage
16-SOIC (0.295", 7.50mm Width)
In Stock
94,293 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UC2842DW
UC2842DW
lmages are for reference only.Payment Methods
Delivery Services
Boost, Buck, Buck-Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-SOIC
Quick Inquiry
UC2842DW
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Unitrode |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Boost, Buck, Buck-Boost, Flyback, Forward |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 12V ~ 28V |
| Frequency - Switching | Up to 500kHz |
| Duty Cycle (Max) | 97% |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Frequency Control |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | UC2842 |
| Grade | - |
| Qualification | - |
