UC3842BD1013TR
lmages are for reference only.UC3842BD1013TR
IC REG CTRLR BST FLYBK ISO 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
90,740 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost, Flyback Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
UC3842BD1013TR
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive, Isolation Capable |
| Topology | Boost, Flyback |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 30V |
| Frequency - Switching | Up to 500kHz |
| Duty Cycle (Max) | 96% |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Frequency Control |
| Operating Temperature | 0°C ~ 70°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | UC3842 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UC3842BD | UC3842BD1 | UC3842BD1 | UC3842BD1G |
| Manufacturer | onsemi | STMicroelectronics | onsemi | onsemi |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC REG CTRLR PWM CM 14-SOIC | IC REG CTRLR BST FLYBK ISO 8-SO | IC REG CTRLR BST FLYBK ISO 8SOIC | IC REG CTRLR BST FLYBK ISO 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
